Client Certificates and Logout

Last Updated May 16, 2022

Back in May 2020, I wrote about Client Certificate Authentication, a mechanism that allows websites to strongly validate the identity of their visitors using certificates presented by the visitor’s browser.

One significant limitation for client certificate authentication is that there is no standards-based mechanism for a user to “log out” of a site that uses that auth mechanism.

Update: “Forget” feature in Edge 102

The Edge team is now testing a feature (which will likely be available by default starting in Edge 102) to allow the user to “forget” which Client Certificate was selected.

Background on Auth Caching

When a user picks a client certificate to authenticate to a server, that choice (an {Origin, ClientCert} tuple) is remembered for the lifetime of the browsing session. Any subsequent CertificateRequest challenge from that origin will automatically be answered by the browser using the previously-selected certificate.

The Auth Caching behavior is necessary for at least two reasons:

  • User-Experience: Client Cert authentication is a connection-oriented authentication protocol– each connection to the server can challenge the user for a client certificate, and the browser re-prompting the user for a new certificate for each new connection would be incredibly annoying.
  • Predictability: Even worse, if the user accidentally picked a different certificate for subsequent connections, the browser would end up in the very confusing state whereby requests might exhibit different behavior based on which reused connection happened to be pulled from the browser’s connection reuse pool when each request is sent.

Unfortunately, tying the Auth cache’s certificate selection to the browsing session means that if a user has multiple certificates, selecting a different certificate for subsequent use on the site (either because the user chose the “wrong” certificate the first time, or because they would like to “switch their identity”) is not generally straightforward.

The only option that works reliably across browsers is to restart the browser entirely (closing all of your other tabs and web applications). Note: You might reasonably expect that closing all of the tabs in a single Profile, then opening a new window in that Profile would be sufficient to clear the certificate selection, but as of Chromium 93, it is not enough– you must fully restart the browser to clear cached Client Certificates and HTTP Auth (e.g. Basic).

Update: This appears to have been improved in Chrome 97, where a new flag was introduced; it’s currently only enabled at 10% but will eventually roll out everywhere.

// Destroy profiles when their last browser window is closed, instead of when
// the browser exits.
const base::Feature kDestroyProfileOnBrowserClose{
    "DestroyProfileOnBrowserClose", base::FEATURE_DISABLED_BY_DEFAULT};

After enabling this FEATURE, closing the last window of a profile successfully clears its certificate selections and Basic auth cache, such that the user is prompted again upon reopening a window in the closed profile.

Log Out Approaches

To address the user desire to “Log out without restarting,” Internet Explorer offered a “Clear SSL State” button buried inside the Internet Control Panel:

… and websites could invoke the same functionality with a web-accessible JavaScript call:

 document.execCommand("ClearAuthenticationCache", false);

Notably, the button and the API both clear all Client Certificates for all sites running in the current session, meaning users cannot log out of just a single site using the API.

The ClearAuthenticationCache API (a blunt hammer with many side-effects) was never standardized, so it was not supported in other browsers.

Instead, the standardized Clear Site Data (MDN) offers a mechanism for websites to programmatically clear per-origin data including Auth Caches (both HTTP Authentication and Client Certificate Authentication). Unlike the IE ClearAuthenticationCache call, Clear-Site-Data is per-origin, so calling it does not blow every site’s data away.

Unfortunately, it’s not very useful for logging users out of Client Cert auth’d sites, for a few reasons:

  1. Websites cannot clear only Auth caches– the Auth caches are instead cleared when the website indicates that it would like cookies cleared.
  2. Websites cannot clear only Session data– when you request that cookies be cleared, it clears not only the Auth caches and session cookies, but also clears the origin’s persistent cookies.
  3. Clearing the Auth Cache alone isn’t enough– the browser also must clear/close any authenticated connections to the origin from the reuse pool, because otherwise a request might reuse a connection previously authenticated with a client certificate.

    The complexity and side-effects of this requirement mean that Chromium has not implemented the clearing of the Auth cache when Clear-Site-Data is called.

Chromium also does not offer any UI mechanism to clear auth caches, meaning that users must restart their browser to clear the auth cache and select different credentials.

Sessions vs. Profiles

Beyond the Clear SSL State button and ClearAuthenticationCache API, Internet Explorer offered users a New Session command that allows a user to open a new browser window that runs in a different Session than the original — the new browser window’s Session does not share Session state (the auth cache, session cookies, sessionStorage) with the original Session. The new Session does however share persistent state (persistent cookies, localStorage, the HTTP Cache, etc), so the two Sessions are not fully isolated from one another.

In contrast, Chromium does not offer such a “New Session” feature. Users can have a maximum of two active Sessions per profile— their “main” Session, and one Private Mode (“Incognito”) session. If a user wishes to have more than two Sessions active at a time, they must load the site using multiple Browser Profiles.

By many measures, this design is “better”– using a different Profile means that all state is isolated between the instances, so you won’t have localStorage, indexedDB data, persistent cookies, or HTTP cache information cross-contaminating your different browser sessions. You’ll also have a handy Profile Avatar in your browser UI to remind you of which account you’re supposed to be using for each window.

However, to an end-user, using different profiles might be less convenient, because profiles isolate all state, not just web platform state. That means that Favorites, Extensions, History and other useful application state are not shared between the two Profiles.

Can anything be done?

There are a variety of investments we might consider to address this use case:

  1. Enhance Chromium’s Clear Site Data feature to match the spec. (The fact that this got punted in Chromium suggests that it’s a hard problem)
  2. Offer the user an explicit mechanism in the browser UI to clear an origin’s Auth cache and empty its connection-reuse pool. (Users will have to learn the new mechanic) Update: This is what we did in Edge 102, see at top
  3. Try to be clever and clear the Auth cache when the user closes the last top-level browser tab to an origin. This is not quite as crazy as it sounds; there have been some discussions of this approach to address the problem of undead session cookies. (Tricky to implement this without undesirable side effects)
  4. Implement something like Firefox Containers to allow one Browser Profile to contain multiple isolated Web Platform-level sessions/profiles. (Expensive, Complicated, Users will have to learn the new mechanic)
  5. The clever and simple solution for this longstanding problem that I simply haven’t thought of yet.

Given the relative obscurity of this scenario, I’m hoping #5 turns up. :)

-Eric

Bonus Content: PINs

One additional behavioral change between IE/Edge Legacy and the new Edge concerns SmartCards whose private keys are protected by a PIN.

Windows typically caches a user-entered PIN on a per-process basis.

In the old model, each tab’s content process contained its own instance of the network stack which was responsible for selection of the certificate (and obtaining the user’s PIN, if required). This means each individual tab would prompt the user for their SmartCard PIN.

In the new model, it’s the browser process that accesses the SmartCard to obtain a selected client certificate, which means that the user is prompted for their PIN only once per browsing session.

Web “Sessions” in Private Mode

I’ve written about Private Browsing Mode a lot previously, and I’ve written a bit about the behavior of “Session restore” previously, but one topic I haven’t covered is how “Sessions” work while in Private mode.

Session Sharing

Historically, one of the top-reported Private Mode issues was that users unexpectedly found that opening a new Private window showed that they were already logged into some site they had used earlier.

From one example issue: The typical explanation when users report issues like this is that the user has multiple Incognito windows open and does not realize that fact. Incognito windows (perhaps surprisingly) are not isolated from one another, and closing one Incognito window does not end the Incognito session. The “background” Incognito window hangs on to all of the login tokens and when you open a new Incognito window, all of those tokens remain available in that new window. Only when all Incognito windows are closed is the session ended and the login tokens expired.

To address this, back in 2018 Chromium implemented an Incognito Window Counter to help the user understand when there are multiple windows in a single Incognito Browsing Session:

If there’s a number in parentheses after the “InPrivate” text, it means that there are more InPrivate windows open in the background. You’ll need to close all of them to end the InPrivate session.

Can We Isolate Each Private Window?

> Cant we just provide a real InPrivate window every time one is
> opened regardless of whether one is open or not already??

Offering “N-isolated InPrivate Windows” (Issue 1024731) is an occasionally-requested feature, but satisfying it would have some tricky subtleties.

In theory, yes, software’s just bits and we can code them any way we want—IE8 exposed an explicit “New Session” command, for instance. So we could make it such that every invocation of “New InPrivate Window” creates a new and isolated Web Session.

Implementing “N-isolated InPrivate windows” has two significant hurdles:

  1. Code – Chromium is presently designed with the idea that there’s a maximum of one InPrivate session per profile. We’d have to carefully trace through every use of the active Profile to create new partitions supporting “N-isolated InPrivate Sessions”, and figure out how UX features like tearing tabs out from an isolated window ought to behave.
  2. UX – Users might not really want every InPrivate window to be isolated from every other InPrivate window. For instance, if you have a website InPrivate and it opens a popup, you probably need that popup to be in the same Session as the parent window, or the flow (script access, any login cookies, etc) is going to break. In a world of “N-isolated InPrivate Sessions”, if you don’t bind the Session tightly to the window, you need to find some way to allow the user to distinguish which windows belong to which Sessions (to ensure, for instance, that closing the last InPrivate window in that isolated Session cleans up exactly the expected state).

Now, in a world of tabbed browsing where most site-initiated popups are automatically created as new tabs in the same window, perhaps we could just punt on the hard UX challenges and decree that every top-level InPrivate Window is isolated to only itself (and e.g. forbid tearing tabs out of that window). It’s hard to say whether the total cost of such a feature would justify the user-perceived benefit.


Rather than using InPrivate for all scenarios, you might also choose to create extra “ephemeral” profiles that throw away all cookies/cache/credentials/etc every time they’re closed, or you can use the existing-by-default “Guest” account for the same purpose.

-E

PS: Long ago, I built a Web Sessions test page in case you’d like to explore the behavior described in this post.

Images Keeping You Awake?

A Microsoft Edge user recently complained that her screensaver was no longer activating after the expected delay, and she thought that this might be related to her browser.

It was, in a way.

To troubleshoot issues where your PC’s screensaver and power-saving options aren’t working correctly, you can use the Power Config command line tool. From an command prompt running as Administrator, run powercfg /requests to see the list of applications requesting that your device keep the display active.

In this case, we see that MSEdge.exe and Teams.exe have active Display Requests. These requests tell Windows that the application wants the screen to remain active and unlocked, usually to display important content (in this case, an ongoing video call and a video playing on a visible tab in Edge, respectively).

After ending my Teams call, only the Edge lock remains. But I don’t think I’m playing any video. What’s up with that?

In Chrome or Edge, you can visit chrome://media-internals to see the list of video content that’s currently playing:

In this case, we see that my Twitter feed is playing back a video. Using the F12 Developer Tools to investigate, we see that (for performance reasons) Twitter serves their animated “GIFs” using MP4 video files:

… and this playback is what’s preventing my screen from going to sleep. Unfortunately, at present there does not appear to be any mechanism for a video tag to indicate that it does not contain important content that requires the display remain active. One proposal is that, for performance reasons, browsers should allow image elements to use video sources <img src="a.mp4" /> and render them as they render animated GIF/PNG today (e.g. no playback controls, allow display to sleep).

Unfortunately, for an end-user there’s not a good workaround for the problem, short of directing Windows to ignore Display Requests from the browser entirely.

-Eric

PS: Beyond media playback, another browser feature that can keep your screen alive is the Screen Wake Lock API, or screencapturing.

File Downloads will allow the screen to turn off, but Chromium will request that the system itself stay awake so that the download will not be interrupted in the middle:

WebRTC connections and file uploads also set an Execution wake lock.

Debugging Browsers – Tools and Techniques

Last update: November 14, 2023

Earlier this year, I shared a post on how you can become an expert on web browsers from the comfort of your desk… or anywhere else you have an internet connection. In that post, I mostly covered how to search through the source, review issue reports, and find design documentation. I also provided a long list of browser experts you might consider following on Twitter.

In today’s post, I’d like to give a quick summary of some of the tools and techniques I use for diagnosing browser problems.

The Importance of Observation

Specs lie. Code misleads. Everything changes over time. Observation reveals what’s actually going on– not what the PM designed, or the Dev intended. If you want to know how something is going to behave, just try it!

This image has an empty alt attribute; its file name is image-16.png

It ain’t what you don’t know that gets you into trouble. It’s what you know for sure that just ain’t so. -various

In many cases, the fastest route to troubleshoot problems is to observe exactly what is happening on the network, disk, or screen and only then start looking at code and specs to figure out why.

Built-in Tools

The F12 Developer Tools (just hit F12) are tremendously useful for determining why a given website behaves in a certain way. In many cases, the DevTools Console will flag an observed problem with a helpful error message. I don’t know of a great tutorial, but there are likely some on YouTube. One non-obvious feature of the DevTools is that you can use a Desktop browser’s DevTools to remote debug a browser running on a mobile device. Another fun fact is that you can use DevTools to debug themselves and some other browser UI.

Chromium’s NetLogs (see chrome://net-export ) contain tons of detailed information about almost every aspect of networking, as well as other useful diagnostic data (the user’s enabled extensions, field trial experimental settings, etc). You can analyze NetLogs using a variety of free tools.

Chromium Tracing (see chrome://tracing ) allows you to diagnose performance issues in Chromium-based browsers using extremely in-depth tracelog data. Analysis of these logs isn’t for the faint-of-heart.

Chromium Histograms (see chrome://histograms) enables you to see events logged by Chromium to be sent to the browser vendor for analysis and detection of problems. For example, when troubleshooting missing cookies, you might look at the Histograms page to see if there’s a Cookie.LoadProblem value indicating that the Cookie database file failed to load, or the OSCrypt values to see whether there was a problem loading the decryption key for that database.

Chromium Logging (using the --enable-logging command line argument) is useful in diagnosing a number of internal issues in Chromium subsystems. Collecting and analyzing these logs is non-trivial, but is sometimes the fastest way to root-cause tricky problems. See the following resources:

Chromium includes over 20 Internals Pages that allow you to view detailed information about media playback, data sync, and other features. Visit chrome://chrome-urls and search for -internals to see the list.

Browser Extensions

The VisBug Chrome Extension – Easily manipulate any page layout, directly in your browser.

postMessage Debugger – This extension prints messages sent with postMessage to the console.

Extension source viewer – View the source of browser extensions directly from the Web Store listing.

Cross-Platform Tools

WireShark allows packet-level analysis of network traffic. This can be useful in rare cases where a network bug depends on the exact packet size and timing.

The Fiddler Web Debugger allows import of NetLog and HAR traffic captures, and enables losslessly capturing requests and responses from any browser. While Fiddler Classic is (effectively) Windows-only, Fiddler Everywhere runs on Windows, Mac, and Linux.

Windows Tools

If you need to watch file or registry key creation/read/write/deletion, or thread/process creations and exits, then Sysinternals Process Monitor has got your back. For instance, this helped us easily root cause a bug where launching a Chromium-based browser would delete a file owned by Chrome.

If you want to explore information about process sandboxing, startup parameters, Job limits, etc, then Sysinternals Process Explorer is the tool to use. For instance, this helped us track down a problem where a browser window was unexpectedly appearing. The user simply closed all browser instances, then waited for an unexpected browser to appear. Then, they looked at the process tree to see what application started it. For instance, in this case, Edge was launched by sr.exe:

If you need to debug a scenario involving drag/drop or copy/paste, you can use ClipSpy (binary only) or NirSoft InsideClipboard.

Bisecting

Bisecting is the process of making a repeated set of observations to determine the build in which a problem appeared (or disappeared). From there, you can easily assign bugs to the right owners for rapid fixes.

See the Bisect Regressions section of this post for details on how to use Chromium’s bisect-builds.py script (which does not require you to build Chromium or download all of its tools and source code) to bisect problems. Here’s another bisection case-study.

I’m sure there are a hundred great tools I’ve omitted. This post will grow over time. If you’ve got a suggestion for a great diagnostic tool, share with us!

-Eric

Local Data Encryption in Chromium

Back in February, I wrote about browser password managers and mentioned that it’s important to understand the threat model when deciding how to implement features and their security protections.

Generally speaking, “keeping secrets from yourself” is a fool’s errand, so it’s a waste of time and effort to encrypt data if you have to store the decryption key in a place that’s accessible to the attacker. That’s one reason why physically local attacks and machines infected with malware are generally outside the browser’s threat model: if an attacker has access to the keys, using encryption isn’t going to protect your data.

Web browsers store a variety of highly sensitive data, including credit card numbers, passwords and cookies (often containing authentication tokens functionally equivalent to passwords). When storing this extra-sensitive data, Chromium encrypts it using AES256 on Windows (AES128 on Linux/Mac), storing the encryption key in an OS storage area. This feature is called local data encryption. Not all of the browser’s data stores use encryption– for instance, the browser cache does not. If your device is at risk of theft, you should be using your OS’ full-disk encryption feature, e.g. BitLocker on Windows.

The profile’s encryption key is protected by OSCrypt: On Windows, the OS Storage area is a DPAPI-encrypted blob1; on Mac, it’s the Keychain; on Linux, it’s Gnome Keyring or KWallet.

Notably, all of these OS storage areas encrypt the AES key using a key accessible to (some or all2) processes running as the user– this means that if your PC is infected with malware, the bad guys can get decrypted access to the browser’s storage areas.

However, that’s not to say that Local Data Encryption is entirely without value– for instance, I recently came across a misconfigured web server that allowed any visitor to explore the server owner’s profile (e.g. c:\users\sally), including their Chrome profile folder. Because the browser key in the profile is encrypted using a key stored outside of the Chrome profile, their most sensitive data remained encrypted.

Similarly, if a laptop isn’t protected with Full Disk Encryption, Local Data Encryption will make a thief’s life harder.

Tradeoffs?

Okay, so Local Data Encryption might be useful. What are the downsides?

The obvious tradeoff is simple and mild: There’s always a performance cost to encrypting and decrypting data. However, AES is extremely fast (>1GB/sec) on modern hardware, and the data size of cookies and credentials is relatively small.

The bigger risk is complexity: If something goes wrong with either of the keys (the browser’s key that encrypts the data or the OS’s key that encrypts the browser’s key), then the user’s cookie and credential data will be unrecoverable. The user will be forced to re-log into every website and re-store all of the credentials in their password manager (or recover their credentials from the cloud using the browser’s sync feature).

Unfortunately, I seem to be a magnet for such problems.

On Mac, Edge recently had a problem where the browser would fail to get the browser key from the OS keychain. The browser would offer to wipe the keychain (losing all of your data), but ignoring the error message and restarting would typically correct the problem. A fix for that bug was recently issued.

On Windows, DPAPI failures are typically silent– your data disappears with nary a message box.

When I first rejoined Microsoft in 2018, a bug in AAD meant that my OS DPAPI key was corrupted, causing Chromium-based browsers to cause lsass to spin a CPU core forever when they launched. Troubleshooting this problem required months of effort.

More recently, we’ve heard from some users on Windows 10 that Edge and Chrome forget their data frequently (and similar effects are seen in other DPAPI-using applications).

Users in this state who visit chrome://histograms/OSCrypt in Chrome or Edge in the browser session where they first notice their sensitive data has gone missing will see an entry inside OSCrypt.Win.KeyDecryptionError with a value of -2146893813 (NTE_BAD_KEY_STATE), indicating that the OS API was unable to use the currently logged-in user’s credentials to decrypt the browser’s encryption key:

Fortunately (for us, not for him), this problem hit one of the best engineers in the world, and he was able to develop a solid theory of the root cause of the problem. If you find your system in this state, try running the following command in PowerShell:

Get-ScheduledTask | foreach { If (([xml](Export-ScheduledTask -TaskName $_.TaskName -TaskPath $_.TaskPath)).GetElementsByTagName("LogonType").'#text' -eq "S4U") { $_.TaskName } }

This will list off any scheduled tasks using the S4U feature suspected of causing the incorrect DPAPI credentials:

Update: The S4U bug was fixed for Windows 10 2004 and 20H2 as a part of the February 2021 Windows Updates.

-Eric

1 Windows’ DPAPI itself uses AES256/SHA2 to encrypt the blob for non-Domain user accounts, but defaults to 3DES/SHA1 for Domain accounts. Administrators who do not need legacy compatibility for their domain users may specify algorithm ids in registry keys to choose among RC4/SHA1, 3DES/SHA1 and AES256/SHA512. You can learn more about hacking DPAPI here.

2 The question of which processes can ask the OS to decrypt the browser’s key is a somewhat interesting one. On Windows, Chromium’s use of DPAPI’s CryptProtectData allows any process running as the user to make the request; there’s no attempt to use additional entropy to do “better” encryption, largely because there’s nowhere safe to store that additional entropy. On modern Windows, there are some other mechanisms that might provide somewhat more isolation than raw CryptProtectData, but full-trust malware is always going to be able to find a way to get at the data. Mid-2024 Update: The Chrome team has introduced an AppBound Encryption feature that locks down the storage on Windows more tightly.

On Mac, the Keychain protection restricts access to data such that it’s not accessible to every process running as the user, but this doesn’t mean the data is immune from malware. Malware on Mac must instead use Chrome as a sock-puppet, having it perform all of the data decryption tasks, driving it via extensibility interfaces or other mechanisms.

The overall threat model against local attackers is further complicated by the mechanisms and constraints of process isolation: for instance, attackers can dump the memory of a browser process, or inject threads into that process, enabling malware to steal the data after the browser has decrypted it.

Mobile platforms (iOS/Android) tend to have the strongest story here, with more robust process isolation, code-signing requirements, hardware-backed secure enclaves that require biometrics for release, etc.
